Operation 72800115 Markoprint X4JET
Seite 78 von 177 GB
Print head module selection
The separate print head modules can be selected by the buttons 1 to 4, underneath the
display. It’s possible to scan the status of the respective print head module and to set up
the parameters of the respective ink cartridges / print head modules. The selected print
head module will be shown by a LED in the respective button field. The LED glows
green. Is the print head made up of multi-print head modules, the LED buttons of the
corresponding print head modules will lighten yellow. The LED buttons of the other print
head modules, which are not a part of the print head, are lapsed.
Example:
Two Twin print heads are connected to the controller. If one print head module is
selected, the LED glow green and the LED of the other print head module yellow. The
LED of the second Twin print head is lapsed.
