Weber Markoprint X4JET User Manual

Appendix 72800115 Markoprint X4JET
Seite 144 von 177 GB
Plugs and sockets
Sensor
Sensor input: 24V
Standard: NPN (switching to GND)
Can be changed to PNP via software
Photocell with 4-pole M8 round plug
PIN
Description
Value
Unit
1
Power
+ 24
V
2 – Sen2
Start pulse (inverted signal)
Input standard NPN
-
3
GND
0
V
4 – Sen1
Start pulse
Input standard NPN
-
The PIN2 can optionally be used as an additional input. This must be programmed
customer-specifically.
Standard is the inverse output by many sensors. The input can selected as sensor 1+2
inverted in the menu.
Signal threshold 12V +- 2V
