Weber Markoprint X4JET - USB A; B; Ethernet

Appendix 72800115 Markoprint X4JET
Seite 157 von 177 GB
USB A / B
The USB sockets are standard sockets, as used in commercial PCs and USB devices.
Insert the USB plug vertically into the USB socket without using force.
PIN
Name
Colour
Description
1
VCC
Red
+5 V
2
D-
White
Data -
3
D+
Green
Data +
4
GND
Black
Mass
Ethernet
Connection Network input RJ 45
PIN
Description
1
Transmit+
2
Transmit-
3
Receive+
6
Receive-
Mac addresses
The MAC address of the respective Markoprint X4JET can be seen on the system
directly.
 Chapter Gate-Way- and MAC address, Page 104
Range from:
To:
00-50-C2-A6-50-00
00-50-C2-A6-5F-FF
