Operation 72800115 Markoprint X4JET
Seite 94 von 177 GB
Print direction
To select the print direction proceed as follows:
1. Touch the iLOGIK once in one of the status menus.
The Label submenu is displayed.
2. Call the Parameter submenu by rotating the iLOGIK and select by pressing.
The Print Delay submenu is displayed.
3. Call the Direction submenu by rotating the iLOGIK and select by pressing.
The Direction submenu is displayed.
4. Make the desired setting by rotating the iLOGIK and select by pressing.
To set the nozzle rows
The setting of the nozzle rows is only possible for using HP print heads.
Each ink cartridge has two nozzle rows (A and B). One nozzle row has 150 nozzles.
The nozzles in row A print the uneven numbers 1, 3, 5, 7
The nozzles in nozzle row B print the even numbers 2, 4, 6, 8
Per nozzle row A or B, 300dpi are printed. In this mode, the nozzles are uniformly
stressed and the speed setting is not as critical as with A + B.
If, for instance, using A ~ B, every second print image is of poor quality, nozzle row A; or
nozzle row B can be activated.
Fig. 39: Nozzle plate ink cartridge
If A + B is set, the print simultaneously with all nozzles in both nozzle rows is printed.
The speed must be synchronized exactly, so that the ink drops lay exactly one upon the
other. Otherwise a shadow is on the print image.
