Appendix 72800115 Markoprint X4JET
Seite 143 von 177 GB
Boot LED messages
During booting of the system progress can be determined by means of the LED.
If the system stops during booting the cause can be determined by means of the LED.
FC means flashing. An error can be determined on the basis of the number of flashes.
LED Power
LED Sensor
Description
ye
ye
Boot BF-Intern
rd
Write 64MB memory
rd
Read/ invert 64MB memory
ye
Read/ test 64MB memory
ye
Test ok / Load BootMain from SPI
ye
rd
Programming and start of BootMain
BootMain initialization
rd
rd
Fatal error
rd
FC: rd
Boot error 4x = SPI; 5x = GA; 6x = Displ; 7x = SD-Card; 8x =
USB; 9x = RTC; 10x = Task
rd
FC: gn
Init error 1x = Dev; 2x = FS; 3x= UsrCl
ye
gn
SD card read
ye
rd / gn
Wait for stick
ye
rd /
No boot data
ye
ye / gn
Booting of stick?
ye
ye / rd
Copying of stick?
ye
gn /
Copy Ok
gn
Main program loaded and started
