iDesign 72800115 Markoprint X4JET
Seite 113 von 177 GB
Load print image
The print image in the print memory is printed by the Markoprint X4JET controller after
each light barrier impulse on the product surface.
A print image can be loaded into the memory of the Markoprint X4JET controller with the
iDesign software via a network connection. This image can then be called in the
controller in the Select Label menu and printed.
The PC software iDesign is included in delivery as installation DVD to create print
layouts and texts.
On the iDesign DVD is an extra instruction how the software is to handle.
Installation
Double click the setup.exe file on the DVD.
The software will be installed to the folder C:\User\Official\iDesign.
To start iDesign click on the iDesign desktop button.
Connection to the system
Standard by USB or Ethernet
The connection is also possible by RS232.
Parameter, Preparation
In iDesign below Connections
click on Add system, adjust the IP address and confirm
with OK, or click on Search on Com Ports. A system which is connected with the USB
slot will be identified automatically.
Text design
With iDesign it’s possible to create print images below Editor.
Fields can be inserted and free positioned in the print image with the buttons Text, Date,
Counter, Barcode, Variable, Logo. The finished print layout can be saved by a name with
max. 8 digits – standard the print images will be saved below Official\iDesign\label, the
storage location can also free selected. The text gets the extension .00I automatically.
Load texts
Send print images to the system or save print images below Functions
Save label.
