Weber Markoprint X4JET User Manual

Appendix 72800115 Markoprint X4JET
Seite 148 von 177 GB
External Output
The outputs are potential-free. The relay is designed for 24V. Relay output: max 24 V
and max. 100 mA.. Standard: Closing contact.
 Connection
15-pole Sub-D-socket.
 Input
NPN input, can be changed to PNP via software.
 Standard
NPN (to GND switching)
 Input voltage for PNP
10 V…24 V
PIN
Name
Description
Potential
1
Out 5
Relay 1
OK
2
Out 5
Relay 1
3
Out 6
Relay 2
Warn
4
Out 6
Relay 2
5
Out 7
Relay 3
Alarm
6
Out 7
Relay 3
7
Out 8
Relay 4
Reserve
8
Out 8
Relay 4
9
max.100
mA
24V internal
+24 V
10
GND
0 V
11
In 1
Input 1
12
In 2
Input 2
13
In 5
Input 5
14
In 6
Input 6
15
NC
