Installation and initial operation 72800115 Markoprint X4JET
Seite 73 von 177 GB
Rinsing the MX print head
Material damage due to ink leavings!
Rinsing of the MX-Top print head results increased ink
consumption and can lead to undesirable contamination
of the environment.
Therefore:
– Secure the environment against leaking ink.
– Afterwards wipe the nozzle plate once with a lint-free
cloth
Rinse the system before the initial operation.
With a short push on the button it happen a flush run, the vacuum pump of the
maintenance station runs to suck off the ink rests. The vacuum pump runs after ca. 1
sec. shortly to rinse ink, air and dust from the nozzles, afterwards the vacuum pump runs
ca. 10 sec. to suck off the ink rests completely.
Instruction
Please rinse the MX print head as follows:
Press the [PURGE] button on the system flange plate.
After rinsing, a test print should be done. If the print result is not satisfactory,
repeat steps bleeding and rinsing.
