Installation and initial operation 72800115 Markoprint X4JET
Seite 71 von 177 GB
Bleed the MX print head
Material damage due to ink leavings!
It can come to undesirable contamination of the
environment by squirting ink during the purging of the MX
print head.
Bleed the system before the initial operation.
If the PURGE button will be pressed more than 20 seconds, the vacuum pump runs
continuously to de-aerate the print head. Therefore the nozzle plate should be closed
with the head clamp to rinse the ink in a circulation.
The pump stops pumping after 30 sec. automatically.
Instruction
Please bleed the MX print head as follows:
Fig. 0-1: Switch the system on
Put the locking clamp on the nozzle plate.
Fig. 0-2: Put the locking clamp on
Press the [PURGE]-button and hold them pressed for ca. 30 seconds.
ATTENTION, ink may leak out of the nozzle plate of the print head.
