Weber Markoprint X4JET - Print Head Cable

Appendix 72800115 Markoprint X4JET
Seite 155 von 177 GB
Print Head Cable
Configuration of the 24+4+1 HP print head cable
PIN
Name
Description
Level
1
DOUT-
out
Lvds
2
DOUT+
out
Lvds
3
AGND
power
0 V
4
DIN_1-
in
Lvds
5
DIN_1+
in
Lvds
6
PWHFIRE-
in
Lvds
7
PWHFIRE+
in
Lvds
8
IR_Signal
out
0 V
9
DIN_2-
in
Lvds
10
DIN_2+
in
Lvds
11
AGND
power
0 V
12
DCLK-
in
Lvds
13
DCLK+
in
Lvds
14
VCC
power
5 V
15
GND
power
0 V
16
res
power
0 V
17
DLOAD-
in
Lvds
18
DLOAD+
in
Lvds
19
AGND
power
0 V
20
HCLK-
in
Lvds
21
HCLK+
in
Lvds
22
AGND
power
0 V
23
HFIRE-
in
Lvds
24
HFIRE+
in
Lvds
C1
VPP
power
24 V
C2
VPP
power
24 V
C3
VPF
power
30 V
C4
VPF
power
30 V
C5
GND
power
0 V
