CHAPTER 5 - START-UP
ACTION
LED DISPLAY
DESCRIPTION
LCD DISPLAY
Motor Rated HP
P
4
0
4
=
5
.
0
C
V
Motor Rated HP
P
4
0
4
=
5
.
0
C
V
FP Nom. Motor
P4
0
7 = 0.68
FP Nom. Motor
P4
0
7 = 0.68
FP Nom. Motor
P4
0
7 = 0.68
FP Nom. Motor
P4
0
7 = 0.68
Press the key to go to the
next parameter
Press the key to enter the
programming mode
Use the and keys
to select the motor rated power
Press the key to save the
programmed value and exit the
programming mode
Press the key to go to the
next parameter
Press the key to enter the
programming mode
Use the and keys to
select the Motor Rated Power Factor
Press the key to save the
programmed value and exit the
programming mode
Motor Rated hp Range:
1 to 1600.0 CV
1 to 1190.0 kW
Enter the programmingmode
Selected Motor Rated Power:
5.0 CV/3.7 kW
Exit the programming mode
Motor Rated Power Factor
0.50 to 0.99
Enter the programmingmode
Motor Power Factor:
0.68
Exit the programming mode
