CHAPTER 8 - CFW-09 OPTIONS AND ACCESSORIES
This position indicates de P003 Parameter content, disregarding the decimal
point. A lowpass filter with a time constant of 0.3 s filters this variable.
The variables are written in the following order:
2 - Motor speed reference,
for option P309 = 1 or 4 (2I/O) - it writes in 1 and 2;
3 - Status of the Digital Outputs;
4 - Number of the Parameter to be read,
for option P309 = 2 or 5 (4I/O) - it writes in 1, 2, 3 and 4;
5 - Number of the Parameter to be changed;
6 - Content of the Parameter to be changed, selected in the previous position,
for option P309 = 3 or 6 (6I/O) - it writes in 1, 2, 3, 4, 5 and 6.
1. Logical Control (C.L.):
The word that defines the C.L. is formed by 16 bits, being 8 bits of high orders
and 8 bits of low orders and having the following construction:
- theyselect the function that shall be driven when the bit is set
To save the changes of the parameter P169/P170 in the EEPROM;
- theydeterminethe statusthatis wantedforthe functionselected
Inverter faultreset: always it varies from 0
1, aninverter reset is caused,
with the presence of faults (except E24, E25, E26 e E27);
No function / STOP detection. It is not necessary to activate the
correspondent upper bit (refer to the description of parameter P310)
To save P169/P170 in the EEPROM: 0 = to save, 1 = to not save;
Local/Remote control: 0 = Local, 1 = Remote;
Jog control: 0 = Inactive, 1 =Active;
Direction of rotation: 0 = counter-clockwise, 1 = clockwise;
General enabling: 0 = Disabled, 1 = Enabled;
Start/Stop: 0 = Stop, 1 = Start.
The inverter will execute only the command indicated in the low-order bit, when
the corresponding high-order bit has the value 1 (one). When the high-order bit
has the value 0 (zero), the inverter will disregard the value of the corresponding
