CHAPTER 8 - CFW-09 OPTIONS AND ACCESSORIES
8.10.3.3 Installation/Connection
Location of the power connections is shown in figures 8.29, 8.30 and 8.31.
X7
BR
-UD
+UD
Figure 8.29
- Connection location
Figure 8.30
- Power terminals
Figure 8.31
- X7 terminal block
X7
M
1~
o
t
1 2 3 4
