WEG CFW-09 User Manual

CFW-09-
QUICK PARAMETER REFERENCE
9
QUICK PARAMETER REFERENCE, FAULT AND STATUS MESSAGES
Software: V
4.0X
Application:
CFW-09 Model:
Serial Number:
Responsible:
Date:
/
/
.
I. Parameters
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
P000
Parameter Access
0 to 999
0
-
118
READ ONLY PARAMETERS
P001 to
P099
P001
Speed Reference
0.0 to P134
rpm
118
P002
Motor Speed
0.0 to P134
rpm
118
P003
Motor Current
0.0 to 2600
A (rms)
118
P004
DC Link Voltage
0.0 to 1235
V
119
P005
Motor Frequency
0.0 to 1020
Hz
119
P006
Inverter Status
rdy
-
119
run
Sub
Exy
P007
Motor Voltage
0 to 800
V
119
P009
Motor Torque
0.0 to 150.0
%
119
P010
Output Power
0.0 to
3276
kW
119
P012
Digital Inputs DI1 ... DI8 Status
0 = Inactive (Open)
-
119
1 = Active (Closed)
P013
DigitalandRelayOutputsDO1,DO2,
0 = Inactive (Dropped-out)
-
120
RL1, RL2, and RL3 Status
1 = Active (Picked-up)
P014
Last Fault
0 to 71
-
121
P015
Second Previous Fault
0 to 71
-
121
P016
Third Previous Fault
0 to 71
-
121
P017
Fourth Previous Fault
0 to 71
-
121
P018
Analog Input AI1’ Value
-100 to +100
%
121
P019
Analog Input AI2’ Value
-100 to +100
%
121
P020
Analog Input AI3’ Value
-100 to +100
%
121
P021
Analog Input AI4’ Value
-100 to +100
%
121
P022
WEG Use
-
-
121
P023
Software Version
V4.0X
-
121
P024
A/D Conversion Value of AI4
-32768 to +32767
-
121
P025
A/D Conversion Value of Iv
0 to 1023
-
121
P026
A/D Conversion Value of Iw
0 to 1023
-
121
P027
AO1 Value
0.0 to 100
%
122
P028
AO2 Value
0.0 to 100
%
122
P029
AO3 Value
-100 to +100
%
122
P030
AO4 Value
-100 to +100
%
122
P040
PID Process Variable
0 to 100
%
122
P042
Powered Time
0 to 65535
h
122
P043
EnabledTime
0 to 6553.5
h
122
P044
kWh Counter
0 to 65535
kWh
123

WEG CFW-09 Specifications

General

Protection Degree	IP20
Cooling Method	Forced ventilation
Power Range	0.18 to 11 kW (0.25 to 15 HP)
Frequency Range	0 to 400 Hz
Overload Capacity	150% for 60 seconds
Braking	DC braking
Communication	RS485, Modbus RTU
Output Voltage	0 to input voltage
Control Type	V/F
