WEG CFW-09 - Power Supply

337
CHAPTER9 -
TECHNICAL
SPECIFICA
TIONS
Model: Current / Voltage
6/
7/
10/
13/
16/
24/
28/
220-230
220-230
220-230
220-230
220-230
220-230
220-230
Load
(1)
CT/VT
CT/VT
CT/VT
CT/VT
CT/VT
CT/VT
CT/VT
Power (kVA)
(2)
2.3
2.7
3.8
5
6.1
9.1
10.7
Rated Output Current (A)
(3)
6
7
10
13
16
24
28
Maximum Output Current (A)
(4)
9
10.5
15
19.5
24
36
42
Rated Input Current (A)
(7)
7.2/15
(6)
8.4/18
(6)
12/25
(6)
15.6
19.2
28.8
33.6
Rated Switching Frequency (kHz)
5
5
5
5
5
5
5
Maximum Motor
(hp)/(kW)
(5)
1.5/1.1
2/1.5
3/2.2
4/3.0
5/3.7
7.5/5.5
10/7.5
Watts Loss (W)
(8)
69
80
114
149
183
274
320
Frame Size
1
1
1
1
2
2
2
9.1.2
220-230 V Power Supply
Model: Current / Voltage
45/
54/
70/
86/
105/
130/
220-230
220-230
220-230
220-230
220-230
220-230
Load
(1)
CT/VT
CT
VT CT VT CT VT CT VT CT VT
Power (kVA)
(2)
18
21
27
28
34
34
42
42
52
52
60
Rated Output Current (A)
(3)
45
54
68
70
86
86
105
105
130
130
150
Maximum Output Current (A)
(4)
68
81
105
129
158
195
Rated Input Current (A)
(7)
54
65
82
84
103
103
126
126
156
156
180
Rated Switching Frequency (kHz)
5
5
2.5
5
2.5
5
2.5
5
2.5
5
2.5
Maximum Motor
(hp)/(kW)
(5)
15/11
20/
25/
25/
30/
30/
40/
40/
50/
50/
60/
15
18.5
18.5
22
22
30
30
37
37
45
Watts Loss (kW)
(8)
0.5
0.6
0.8
0.8
1.0
1.0
1.2
1.2
1.5
1.5
1.7
Frame Size
3
4
5
5
6 6
9.1.3
380-480 V Power Supply
Model: Current / Voltage
3.6/
4/
5.5/
9/
13/
16/
24/
380-480
380-480
380-480
380-480
380-480
380-480
380-480
Load
(1)
CT/VT
CT/VT
CT/VT
CT/VT
CT/VT
CT/VT
CT/VT
Power (kVA)
(2)
2.7
3.0
4.2
6.9
9.9
12.2
18.3
Rated Output Current (A)
(3)
3.6
4
5.5
9
13
16
24
Maximum Output Current (A)
(4)
5.4
6
8.3
13.5
19.5
24
36
Rated Input Current (A)
(7)
4.3
4.8
6.6
10.8
15.6
19.2
28.8
Rated Switching Frequency (kHz)
5
5
5
5
5
5
5
Maximum Motor
(hp)/(kW)
(5)
1.5/1.1
2/1.5
3/2.2
5/3.7
7.5/5.5
10/7.5
15/11
Watts Loss (W)
(8)
60
66
92
152
218
268
403
Frame Size
1
1
1
1
2
2
2
Note:
CT
= Constant Torque
VT
= Variable Torque
FactoryDefault
