WEG CFW-09 - Installation and Connection; Mechanical Installation; Environment Conditions; Dimensional of CFW-09

43
CHAPTER 3 - INSTALLATIONANDCONNECTION
Model
Height
Width
Depth
Mounting
Degree of
H
L
P
A
B
C
D
Screw
Weight
Protection
mm
mm
mm
mm
mm
mm
mm
mm
Kg
(in)
(in)
(in)
(in)
(in)
(in)
(in)
(in)
(lb)
Size 1
210
143
196
121
180
11
9.5
M5
3.5
NEMA1/
(8.27)
(5.63)
(7.72)
(4.76)
(7.09)
(0.43)
(0.37)
(3/16)
(7.7)
IP20
Size 2
290
182
196
161
260
10.5
9.5
M5
6.0
(11.42)
(7.16)
(7.72)
(6.34)
(10.24)
(0.41)
(0.37)
(3/16)
(13.2)
Size 3
390
223
274
150
375
36.5
5
M6
19.0
(15.35)
(8.78)
(10.79)
(5.90)
(14.76)
(1.44)
(0.20)
(1/4)
(41.9)
Size 4
475
250
274
150
450
50
10
M6
22.5
(18.70)
(9.84)
(10.79)
(5.90)
(17.72)
(1.97)
(0.39)
(1/4)
(49.6)
Size 5
550
335
274
200
525
67.5
10
M8
41
(21.65)
(13.19)
(10.79)
(7.87)
(20.67)
(2.66)
(0.39)
(5/16)
(90.4)
Size 6
675
335
300
200
650
67.5
10
M8
55
(26.57)
(13.19)
(11.77)
(7.87)
(25.59)
(2.66)
(0.39)
(5/16)
(121.3)
Size 7
835
335
300
200
810
67.5
10
M8
70
(32.87)
(13.19)
(12.20)
(7.87)
(31.89)
(2.66)
(0.39)
(5/16)
(154.3)
Size 8
975
410
370
175
950
67.5
10
M8
100
(38.38)
(16.14)
(14.57)
(10.83)
(37.40)
(2.66)
(0.39)
(5/16)
(220.5)
Size 8E
1145
410
370
275
1120
67.5
10
M8
115
(45.08)
(16.14 )
(14.57)
(10.83)
(44.09)
(2.66)
(0.39)
(5/16)
(253)
Size 9
1020
688
492
275
985
69
15
M10
216
IP20
(39.37)
(27.56)
(19.33)
(10.83)
(37.99)
(2.95)
(0.59)
(3/8)
(476.2)
Size 10
1185
700
492
275
1150
69
15
M10
259
(46.65)
(27.56)
(19.33)
(10.83)
(45.27)
(2.95)
(0.59)
(3/8)
(571)
Size 10E
1185
700
582
275
1150
69
15
M10
310
(46.65)
(27.56)
(22.91)
(10.83)
(45.27)
(2.95)
(0.59)
(3/8)
(682)
Table 3.1 -
Installation data – Refer to item 9.1
For installing the CFW-09, leave at least the minimum free spaces around the
inverteraccordingto figure3.2.Thedimensions ofthesefreespaces aredescribed
on table 3.2.
Install the inverter in the vertical position according to the following
recommendations:
1)
Install the inverter on a flat surface.
2)
Donotinstallheat sensitive components immediatelyabove the inverter.
3)
For the inverters 45 A to 130 A/220-230 V, 30 A to 600 A/380-480 V, 22 A
to 32 A/ 500-600 V, 44 A to 79A/500-600 V, 107 A to 472 A/500-690 V and
100 A to 428 A/660-690 V:
-
First partially tighten the bolts on the surface, then install the inverter
and screw-down the bolts.
4)
For inverters 6 A to 28 A/220-230 V, 3.6 A to 24 A/380-480 V and 2.9A to
14A/500-600 V:
-
Install the 2 bottom mounting bolts first, rest the inverter on the base and
then mount the 2 top bolts.
3.1.3
Mounting Specifications
