CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
Range
[Factory Setting]
Parameter
Unit
Description / Notes
6.4
MOTOR PARAMETERS - P400 to P499
P400
(1) (6)
0 to 690
Motor Rated Voltage
[ P296 ]
1 V
Set this parameter value according to the motor nameplate and the
connection diagram in the terminal box.
This value cannot be greater than the rated voltage value set at P296.
In order to make a new setting of P400 effectivewhile not in the guided
start-up routine, it is necessary to power the inverter down/up.
P402
(1) (2) (11)
0 to 18000
Motor Rated Speed
[ 1750 (1458) ]
1 rpm
0 to 7200
[ 1750 (1458) ]
1 rpm
Set this parameter according to the motor nameplate.
0 to 18000 rpm for V/F and VVW Control.
0 to 7200 rpm for Vector Control.
P403
(1) (11)
0 to 300
Motor Rated
[ 60 (50) ]
Frequency
1 Hz
30 to 120
[ 60 (50) ]
1 Hz
Set this parameter according to the motor nameplate.
0 to 300 Hz for V/F and VVW Control.
30 to 120 Hz for Vector Control.
P404
(1)
0 to 50
Motor Rated Power
[ 4 ]
-
Set this parameter according to the motor nameplate.
P401
(1) (12)
0.0 to 1.30 x P295
Motor Rated Current
[ 1.0 x P295 ]
0.1A(< 100)-1A(> 99.9)
Set this parameter according to the motor nameplate, considering the
motoroperating voltage.
Table 6.59
- Motor rated power selection
P404
Motor Rated
Power (hp
/kW)
P404
Motor Rated
Power (hp
/kW)
0
0.33/0.25
26
180.0/132.0
1
0.50/0.37
27
200.0/150.0
2
0.75/0.55
28
220.0/160.0
3
1.0/0.75
29
250.0/185.0
4
1.5 /1.1
30
270.0/200.0
5
2.0 /1.5
31
300.0/220.0
6
3.0 /2.2
32
350.0/260.0
7
4.0 /3.0
33
380.0/280.0
8
5.0 /3.7
34
400.0/300.0
9
5.5 /4.0
35
430.0/315.0
10
6.0/4.5
36
440.0/330.0
11
7.5/5.5
37
450.0/335.0
12
10.0/7.5
38
475.0/355.0
13
12.5/9.0
39
500.0/375.0
14
15.0/11.0
40
540.0/400.0
15
20.0/15.0
41
600.0/450.0
16
25.0/
18.5
42
620.0/460.0
17
30.0/22.0
43
670.0/500.0
18
40.0/30.0
44
700.0/525.0
19
50.0/37.0
45
760.0/570.0
20
60.0/45.0
46
800.0/600.0
21
75.0/55.0
47
850.0/630.0
22
100.0/75.0
48
900.0/670.0
23
125.0/90.0
49
1100.0/ 820.0
24
150.0/110.0
50
1600
.0
/119
0.0
25
175.0/130.0
