344
CHAPTER9 -
TECHNICAL
SPECIFICA
TIONS
KEYPAD
ST
ANDARD
(HMI)
(HMI-CFW09-LCD)
DEGREEOF
NEMA1/IP20
PROTECTION
PROTECTED
CHASSIS/ IP20
8 Keys: Start, Stop, Increase, Decrease, FWD/REV, JOG, Local/Remote and
Program
LCD display: 2 lines x 16 characters
LED display: 4 digits with 7 segments
LEDs for FWD/REV and LOC/REMindication
Display Accuracy:
- Current: 5 % of Rated Current
- Speed Resolution: 1 rpm
Remote mounting possibility,
cables available up to 10 m (30 ft)
NEMA1/ IP20: 3.6A to 240A/380-480 V models and all 220-230V and 500-600 V
models and 107 A to 211 A/500-690 V and 100 A to 179 A/660-690 V.
Protected chassis/IP20: 361 A to 600 A/380-480 V models, 247 A to 472 A/500-
690 V and 225 A to 428 A/660-690 V.
(1)
Available in models

30 A / 220-230 V or

30 A / 380-480 V or

22 A / 500-600 V or for all 500-690 V and 660-690 V models.
9.2.1Applicable Standards
UL508C
- Power conversion equipment.
UL840
-
Insulation coordination including clearances and creepage distances for electrical equipment.
EN50178
- Electronic equipment for use in power installations.
EN60204-1
- Safety of machinery. Electrical equipment of machines. Part 1: General requirements.
Provisions for compliance
: the final assembler of the machine is responsible for installing:
- an emergency-stop device.
- a supply disconnecting device.
EN60146 (IEC 146)
- Semiconductor convertors.
EN61800-2
- Adjustable speed electrical power drive systems - Part 2: General requirements - Rating
specifications for low voltage adjustable frequency AC power drive systems.
EN 61800-3
- Adjustable speed electrical power drive systems - Part 3: EMC product standard
including specific test methods.
EN55011
- Limits and methods of measurement of radio disturbance characteristics of industrial,
scientific and medical (ISM) radio-frequency equipment.
CISPR11
- Industrial, scientific and medical (ISM) radio-frequency equipment - Electromagnetic
disturbance characteristics - Limits and methods of measurement.
EN61000-4-2
- Electromagnetic compatibility (EMC) - Part 4: Testing and measurement techniques -
Section 2: Electrostatic discharge immunity test.
EN61000-4-3
- Electromagnetic compatibility (EMC) - Part 4: Testing and measurement techniques -
Section 3: Radiated, radio-frequency, electromagnetic field immunity test.
EN61000-4-4
- Electromagnetic compatibility (EMC) - Part 4: Testing and measurement techniques -
Section 4: Electrical fast transient/burst immunity test.
EN61000-4-5
- Electromagnetic compatibility (EMC) - Part 4: Testing and measurement techniques -
Section 5: Surge immunity test.
EN61000-4-6
- Electromagnetic compatibility (EMC)- Part 4: Testing and measurement techniques -
Section 6: Immunity to conducted disturbances, induced by radio-frequency fields.
EN60529
- Degrees of protection provided by enclosures (IP code).
UL50
- Enclosures for electrical equipment.
GENERAL
EMC
MECHANICAL
