QUICK PARAMETER REFERENCE
- Interdependence among parameters: parameters that change the settings of
others when modified versus parameters that are automatically modified as a function of a
parameter setting (during start-up and/or normal operation)
Output Overcurrent/Short-Circuit
Power Supply Undervoltage/Phase Loss
Inverter Overtemperature/Pre-charge Circuit
Output Overload (I x t Function)
Valid for P202 = 4 (Vector with Encoder)
Error in the Copy Function
Dynamic Braking Resistor Overload
Motor or Encoder with Inverted Wires
(Self-Tuning) (Valid for P202 = 4)
Serial communication error
Long period at torque limitation
Internal DC Supply Undervoltage
E04 can be "Pre-charge Circuit Failure" only in the following models:
44 A/500-600 V and for all 500-690 V and
660-690 V models. E04 can also occur when signal with inverted polarity is applied
at analog inputs AI1/AI2. The E04 fault message can also occur in the models up to
130 A/ 200-230 V, 142 A/380-480 V and 63 A/500-600 V when the temperature at
the heatsink is lower than -10 ºC.
Condition where it occurs
Parameters that are affected
and modified automatically
P223, P225, P226, P228, P237,
P156, P157, P158, P169 (V
P151, P153, P321, P322, P323
P122, P123, P124, P125, P126,
P127, P128, P129, P130, P131,
