WEG CFW-09 - Page 31

CFW-09-
QUICK PARAMETER REFERENCE
32
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
P527
PIDAction
0 = Direct
0 = Direct
-
224
1 = Reverse
P528
Process Variable Scale Factor
0 to 9999
1000
-
225
P529
Decimal Point of Proc. Var.
0 to 3
1
225
P530
Engineering Unit of Proc. Var. 1
32 to 127 (ASCII)
37 = %
-
226
A, B, ... , Y, Z
0, 1, ... , 9
#, $, %, (, ), *, +, ...
P531
Engineering Unit of Proc. Var. 2
32 to 127 (ASCII)
32 = blank
-
226
A, B, ... , Y, Z
0, 1, ... , 9
#, $, %, (, ), *, +, ...
P532
Engineering Unit of Proc. Var. 3
32 to 127 (ASCII)
32 = blank
-
226
A, B, ... , Y, Z
0, 1, ... , 9
#, $, %, (, ), *, +, ...
P533
Value of Proc. Var. X
0.0 to 100
90.0
%
226
P534
Value of Proc. Var. Y
0.0 to 100
10.0
%
226
P535
Wake Up Band
0 to 100
0
%
227
P536
(1)
Automatic Setting of P525
0 = Active
0 = Active
-
227
1 = Inactive
P537
Hysteresis for Set point =
1 to 100
1
%
227
Process Variable
P538
Hysteresis for VPx/VPy
0.0 to 50.0
1.0
%
227
Notes presented on Quick Parameter Description:
(1)
Parameter can be changed only with the inverter disabled
(motor stopped).
(2)
Values may change as a function of the “Motor Parameters”.
(3)
Values may change as a function of P413 (Tm Constant - obtained during
Self-tuning).
(4)
Values may change as a function of P409 and P411 (obtained during Self-
tuning).
(5)
Values may change as a function of P412 (Tr Constant - obtained during
Self-tuning).
(6)
Values may change as a function of P296.
(7)
Values may change as a function of P295.
(8)
Values may change as a function of P203.
(9)
Values may change as a function of P320.
(10)
User’s Standard (for new inverters) = without parameter.
(11)
The inverter will be delivered with settings according to the market,
considering the HMI language, V/F 50 Hz or 60 Hz and the required voltage.
The reset of the standard factory setting may change the parameters related
to the frequency (50 Hz/60 Hz). Values within parenthesis mean the factory
setting for 50 Hz.
(12)
The maximum value of P156 and P401 is 1.8 x P295 for model 4.2 A/500-
600 V and 1.6 x P295 for models 7 A and 54A/220-230 V; 2.9 A and 7 A/500-
600 V; 107A, 147Aand 247A/500-690 V; 100A, 127 Aand 340A/660-690 V.
