QUICK PARAMETER REFERENCE
31
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
According to the
motor rated power
(P404)

33 = 380.0
hp
/280.0 kW
34 = 400.0
hp
/300.0 kW
35 = 430.0 hp/315.0 kW
36 = 440.0 hp/330.0 kW
37 = 450.0
hp
/335.0 kW
38 = 475.0 hp/355.0 kW
39 = 500.0
hp
/375.0 kW
40 = 540.0 hp/400.0 kW
41 = 600.0
hp
/450.0 kW
42 = 620.0 hp/460.0 kW
43 = 670.0 hp/500.0 kW
44 = 700.0
hp
/525.0 kW
45 = 760.0
hp
/570.0 kW
46 = 800.0
hp
/600.0 kW
47 = 850.0 hp/630.0 kW
48 = 900.0 hp/670.0 kW
49 = 1100.0 hp/820.0 kW
50 = 1600.0 hp/1190.0 kW
P405
(1)
EncoderPPR
250 to 9999
1024
ppr
215
P406
(1)
Motor Ventilation Type
0 = Self Ventilated
0 = Self Ventilated
-
215
1 = Separate Ventilation
2 = Optimal Flux
3 = Increased Protection
P407
(1) (2)
Motor Rated Power Factor
0.50 to 0.99
-
216
Measured Parameters
P408
(1)
Self-Tuning
0 = No
0 = No
-
216
1 = No Rotation
2 = Run for I
mr
3 = Run for Tm
4 = EstimateTm
P409
(1)
Motor Stator Resistance (Rs)
0.000 to 77.95
0.000
217
P410
Motor Magnetizing Current (I
mr
)
(0.0 to 1.25) x P295
0.0
A
218
P411
(1)
Motor Flux Leakage Inductance ( LS)
0.00 to 99.99
0.00
mH
218
P412
L
R
/R
R
Constant (Rotor Time
0.000 to 9.999
0.000
s
218
Constant (Tr))
P413
(1)
Tm
Constant (Mechanical Time
0.00 to 99.99
0.00
s
219
Constant)
SPECIAL FU
NCTION PARAMETERS P520
to
P538
PID Regulator
P520
PIDProportional Gain
0.000 to 7.999
1.000
-
223
P521
PIDIntegral Gain
0.000 to 7.999
0.043
-
223
P522
PID Differential Gain
0.000 to 3.499
0.000
-
223
P523
PIDRampTime
0.0 to 999
3.0
s
223
P524
(1)
Selection of PID Feedback
0 =AI2 (P237 to P240)
0 =AI2 (P237 to P240)
-
223
1 =AI3 (P241 to P244)
P525
PID Setpoint
0.0 to 100.0
0.0
%
224
P526
Process Variable Filter
0.0 to 16.0
0.1
s
224
