WEG CFW-09 - Access and Read Only Parameters - P000 to P099

118
CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
6.1 ACCESS AND READ ONLY PARAMETERS - P000 to P099
Thisparameter openstheaccesstochangeotherparameter values.When
P200 = 1 (Password Active)] it is necessary to set P000 = 5 to change
parameter values.
By programming P000 with the password that releases access to
changing of parameter content plus 1 (Password + 1), you will obtain
access only to the parameters with different content that the factory
default setting.
To change the password to any other value (password 1), proceed as
follows:
1) Set P000 = 5 (current password) and P200 = 0 (password inactive).
2) Press the Key
.
3) Change P200 to 1 (password active).
4) Press
again: display shows: P000.
5)
Press
again: display shows 5 (last password).
6) Use the
and
keys to change to the desired password
value(password 1).
7) Press
: display shows P000. From this moment on, the new
password becomes active. Thus, to change parameters content P000
has to be set to the new password (password 1).
P000
0 to 999
Parameter Access/
[ 0 ]
Password Value
-
Setting
P001
0.0 to P134
Speed
[ - ]
Reference
1 rpm
P002
0.0 to P134
Motor Speed
[ - ]
1 rpm
Range
[Factory Setting]
Parameter
Unit
Description / Notes
Speed Reference value in rpm (FactoryDefault). With filter of 0.5 s.
Thedisplayedunits canbe changed from rpmtoother units at parameters
P207, P216 and P217. The scale factor can be changed at P208 and
P210.
It does not depend on the speed reference source.
Throughthis parameteris possible to changethespeed reference(P121)
when P221 or P222 = 0.
Indicates the actual motor speed in rpm, (factory default). With filter of
0.5 s.
Thedisplayedunits canbe changed from rpmtoother units at parameters
P207, P216 and P217. The scale factor can be changed at P208 and
P210.
Throughthis parameteris possible to changethespeed reference(P121)
when P221 or P222 = 0.
P003
0.0 to 2600
Motor Current
[ - ]
0.1 A(< 100)
-1A(> 99.9)
Indicates inverter output current in ampère (A).
