WEG CFW-09 - Page 13

CFW-09-
QUICK PARAMETER REFERENCE
14
4 = DI2 to DI8
5 = Serial (L)
6 = Serial (R)
7 = Fieldbus (L)
8 = Fieldbus (R)
9 = PLC (L)
10 = PLC (R)
P221
(1)
Local Speed Reference Selection
0 = keypad
0 = Keypad
-
155
1 = AI1
2 = AI2
3 = AI3
4 = AI4
5 = Add AI > 0
6 = Add AI
7 = E.P.
8 = Multispeed
9 = Serial
10 = Fieldbus
11 = PLC
P222
(1)
Remote Speed Reference
0 = keypad
1 = AI1
-
155
Selection
1 = AI1
2 = AI2
3 = AI3
4 = AI4
5 = Add AI > 0
6 = Add AI
7 = E.P.
8 = Multispeed
9 = Serial
10 = Fieldbus
11 = PLC
P223
(1) (8)
Local FWD/REV Selection
0 = Always Forward
2 = Keypad
-
156
1 = Always Reverse
(Default FWD)
2 = Keypad (Default FWD)
3 = Keypad (Default REV)
4 = DI2
5 = Serial (Default FWD)
6 = Serial (Default REV)
7 = Fieldbus (Default FWD)
8 = Fieldbus (Default REV)
9 = PolarityAI4
10 = PLC (FWD)
11 = PLC (REV)
P224
(1)
Local Start/Stop Selection
0 = [I] and [O] Keys
0 = [I] and [O] Keys
-
156
1 = DIx
2 = Serial
3 = Fieldbus
4 = PLC
P225
(1) (8)
Local JOG Selection
0 = Disable
1 = Keypad
-
156
1 = Keypad
Parameters
Function
Adjustable Range
Factory
Unit
User's
Page
Setting
Setting
