WEG CFW-09 - Page 199

200
CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
Range
[Factory Setting]
Parameter
Unit
Description / Notes
P314
(1)
0.0 to 999.0
Time for Serial
[ 0.0 ]
Watchdog Action
0.1 s
P314
Time for serial
watchdog action
0.0
Disable
0.1 to 999.0
Enable
If the inverter does not receive any valid serial telegram after the time
programmed at P314 has elapsed, the Fault Message E28 on the HMI
and the inverter will return to the action programmed at P313 - Type of
Disabling by E28/E29/E30.
To enable the inverter to execute this action, the inverter commands
must be programmed to the “Serial” option at the parameters P220 to
P228.
Table 6.53 -
Serial Watchdog action
P318
0 or 1
Watchdog detection
[ 0 ]
for the PLC board
-
P318
Function
Description
0
Off
Disables the activation
of the Watchdog Error
for the PLC board
-
E71.
1
On
Enables the activation
of the Watchdog Error
for the PLC board
-
E71.
Table 6.54 -
Watchdog detection for the PLC board
P320
(1)
0 to 3
Flying Start/Ride-
[ 0 (Inactive) ]
Through
-
Table 6.55 -
Flying Start/Ride-Through
The Parameter P320 selects the use of the following functions:
P320
0
1
2
3
Function
Inactive
Only Flying Start is active
[valid for P202 = 0, 1, 2 (V/F Control), 3 (sensorless) or 5 (VVW)]
Flying Start and Ride-Through are active
[valid for P202 = 0, 1, 2 (V/F Control), 3 (sensorless) or 5 (VVW)]
Only Ride-Through is active
P321
(6)
178 V to 282 V
Ud Line Loss Level
(P296 = 0)
[252 V]
1 V
The activation of the Ride-Through function can be visualized at the
outputs DO1, DO2, RL1, RL2 and/or RL3 (
P275, P276, P277
,
P279
and/orP280
)providedtheyarealsoprogrammedto “23=Ride-Through”.
This parameter
is shown on the
display
(s)
onlywhen
P202 = 3 or 4
(VectorControl)
307 V to 487 V
(P296 = 1)
[436 V]
1 V
NOTE!
When oneofthefunctions,Ride-ThroughorFlyingStart is activated,
theparameter P214 (Line Phase Loss Detection) is automatically
set to 0 = Off.
