219
CHAPTER 6 - DETAILED PARAMETER DESCRIPTION
P413
(1)
0.00 to 99.99
Tm Constant
[ 0.00 ]
(MechanicalTime
0.01 s
Constant)
The setting of P413 determines the gains of the speed regulator (P161
and P162).
When P408 = 1 or 2, observe the following:
-
If P413 = 0, then the Tm constant will be obtained as a function of the
motor inertia (memorystored value).
-
If P413 > 0, then the value of P413 will not be changed during the self-
tuning routine.
Sensorless Vector Control (P202 = 3):
When the value of P413 (obtained from the self-tuning routine) provides
unsuitable gains for the speed regulator, modifythis parameter to better
adjust the speed regulator gains.
The value of P161, provided by the self-tuning routine or through the
changing of P413, will be limited in the range: 6.0

P161

9.0.
The value of P162 varies according to the value of P161.
In case it is needed to increase more these gains, set them directly at
P161 and P162.
Note:
Valuesof P161> 12.0 maycause oscillations in the torque current
(iq) and in the speed.
Vector with Encoder Control (P202 = 4):
The value of P413 is estimated by the self-tuning routine when P408 = 3
or4. Incase itis notpossible to estimate it, thesetting shall be performed
manually. (Refer to P161/P162).
This parame-
ter is shown on the
display(s)onlywhen
P202 = 3 or 4
(VectorControl)
Range
[Factory Setting]
Parameter
Unit
Description / Notes
Motor Power
CV-hp / kW
2 / 1.5
5 / 3.7
10 / 7.5
15 / 11
20 / 15
30 / 22
50 / 37
100 / 75
150 / 110
200 / 150
300 / 220
350 / 250
500 / 375
T
R
(s)
:
Number of poles
2
(50 Hz/60 Hz)
0.19 / 0.14
0.29 / 0.29
- / 0.38
0.52 / 0.36
0.49 / 0.51
0.70 / 0.55
- / 0.84
1.64 / 1.08
1.33 / 1.74
- / 1.92
- / 2.97
- / -
- / -
4
(50 Hz/60 Hz)
0.13 / 0.14
0.18 / 0.12
0.32 / 0.25
0.30 / 0.25
0.27 / 0.29
0.37 / 0.34
0.55 / 0.54
1.32 / 0.69
1.05 / 1.01
- / 0.95
1.96 / 2.97
1.86 / 1.85
- / 1.87
6
(50 Hz/60 Hz)
0.1 / 0.1
- / 0.14
0.21 / 0.15
0.20 / 0.22
0.38 / 0.2
0.35 / 0.37
0.62 / 0.57
0.84 / 0.64
0.71 / 0.67
- / 0.65
1.33 / 1.30
- / 1.53
- / -
8
(50 Hz/60 Hz)
0.07 / 0.07
0.14 / 0.11
0.13 / 0.14
0.28 / 0.22
0.21 / 0.24
- / 0.38
0.31 / 0.32
0.70 / 0.56
- / 0.67
- / 1.03
- / -
- / -
- / -
Table 6.63 -
Typical T
R
values for some WEG standard motors
Typical T
R
values for WEG standard motors:
