259
CHAPTER 8 - CFW-09 OPTIONS AND ACCESSORIES
To meet NEMA 250 and IEC 60529 the HMI can be supplied with two
specific degrees of protection:
a) Dimensions of the HMI – CFW09 – LED/LCD with NEMA 5-IP51 degree of protection.
Figure 8.13
- Standard HMI, remote HMI frame kit and HMI CFW09 – LCD N4 for panel
installation
Keypad Dimensions
65
(2.56)
23
(0.9)
19
(0.75)
65
(2.56)
113
(4.45
)
113
(4.45)
18
(0.71)
35
(1.43)
2 (0.08)
15
(0.59)
103
(4.05)
16
(0.63)
5
(0.2)
5
(0.2)
Front View
Back View
Cutout Dimensions for Panel
Door Installation
4.0 (2x)
Screw M3x8 (2x)
Torque 0.5Nm
Figure 8.14 a)
- Keypad dimensions in mm (inch) and mounting procedures
