CHAPTER 8 - CFW-09 OPTIONS AND ACCESSORIES
Table 8.
8
-
Connections for remote keypad
cable from 7.5 m
(
22 ft
)
to 10 m
(
30 ft
)
Table 8.7
- Connections for remote keypad
cable up to 5 m (15 ft)
Signal
+5 V
Rx
Tx
GND
+15 V
SHIELD
CABLE CONNECTION 5 m

(
15
ft)
Connector Pin/
Inverter Side
1
2
3
4
8
9
Note:
The frame can be used or not.
HMI
Inverter
Figure 8.15
- Cable for remote keypad connection

10 m
Inverter
key pad (HMI)
Max. recommended cable length: 10 m (30 ft)
Connector DB9 - Male
Connector DB9 - Female
Insert spacer to connect
the cable to the inverter.
Remote HMI connection for distances higher than 10 m (30 ft):
The HMI can be connected to the inverter using a cable length up to 200 m
(600 ft). It is necessary to use an external power supply of 15 Vdc, according
to figure 8.16.
IHM
Inversor
+15V
@300 mA
- Screw
- Do not use nut and washer
GND
Connector Pin/
HMI Side
2
3
4
8
9
CABLE CONNECTION
>
5 m (
> 15
ft)
Connector Pin/
Inverter Side
2
3
4
8
9
Note:
The frame must be used.
Figure 8.16
- Cable for remote keypad connection > 10 m
External power supply
Remote HMI connection for distances lower than 10 m (30 ft):
Connector Pin/
HMI Side
1
2
3
4
8
9
Signal
Rx
Tx
GND
+15 V
SHIELD
