WEG CFW-09 - Page 307

308
CHAPTER 8 - CFW-09 OPTIONS AND ACCESSORIES
EL8:
0 = ramp enabling (run/stop) inactive
1 = ramp enabling
EL9:
0 = general enablinginactive
1 = general enabling active
EL10:
0 = reverse
1 = forward
EL11:
0 = JOG inactive
1 = JOG active
EL12:
0 = local
1 = remote
EL13:
0 = withoutundervoltage
1 = withundervoltage
EL14 :
not used
EL15:
0 = without error
1 = with error
Inverter
enabled
EL8 = EL9 = 1
Error Code: hexadecimal error number
Ex.:
E00

00H
E01

01H
E10

0AH
Selection of the Logical Control
Writing variable, whose bits have the following meaning:
BYTE HIGH: desired action mask. The corresponding bit should be set to 1, so
the action happens.
BYTE LOW: logical level of the desired action.
- CL0:
1 = enabling (Start)
0 = disabling by ramp (Stop)
- CL1:
1 = enabling
0 = general disabling (stops by inertia)
- CL2:
1 = forward
0 = reverse
- CL3:
1 = JOG active
0 = JOG inactive
- CL4:
1 = remote
0 = local
- CL8: 1 = enabling ramp (Start/Stop)
- CL9: 1 = general enabling
- CL10: 1 = Forward/Reverse rotation
- CL11: 1 = JOG
- CL12: 1 = Local/Remote
- CL13: not used
- CL14: not used
- CL15: 1 = inverter “RESET”
V03 (code 00803):
CL15
CL14
CL13 CL12 CL11
CL10
CL9 CL8
MSB
LSB
CL7 CL6 CL5 CL4 CL3
CL2
CL1 CL0
MSB
LSB
