WEG CFW-09 - Page 351

352
CHAPTER9 -
TECHNICAL
SPECIFICA
TIONS
Air Flow
outlet
Air Flow
inlet
Air Flow
outlet
Air Flow inlet
34
(1.34)
34
(1.34)
300(11.81)
229.5 (9.04)
171.5 (6.75)
85(3.35)
168(6.61)
251(9.88)
9.2(0.36)
9.2(0.36)
10 (0.39)
14.6(0.57)
20
(0.79)
29.6(1.17)
15 (0.59)
67.5(2.66)
200(7.87)
15 (0.59)
835(32.87)
335(13.19)
84.5(3.33)
810(31.89)
810(31.89)
337(13.27)
200(7.87)
68.5(2.70)
14 (0.55)
840(37.07)
812(31.97)
Conduit for
power
cable
(3x) 63.0

SIZE 7
Figure 9.8
- Size 7 - dimensions in mm (inch)
