WEG CFW-09 - CFW-09 Identification Label and Code Number

40
Manual
language:
P
=
P
ortuguese
E = English
S = Spanish
Options:
S = standard
O = with options
(refer to note)
Enclosure
degree of
protection:
Blank =
Standard
N4 = NEMA 4
IP56
(
Refer to
chapter 8)
HOW TO SPECIFY THE CFW-09MODEL:
CFW-09
0016
T
3848
E
O
_ _
_ _
_ _
_ _
_ _
_ _
_ _
Z
Keypad (HMI):
Blank =
Standard
IL = Keypad
LED display
only
SI = without
keypad
(
Refer to
note)
Braking:
Blank =
Standard
RB =
Regenerative
Converter
(Active Front
end unit).
DB =
Dynamic
Braking
(
Refer to
chapter 8)
Expansion
Boards:
Blank = Standard
A1 = EBA Board
Complete
B1 = EBB Board
Complete
C1 = EBC1
Board
Complete
E1 = EBE Board
complete
P1 = PLC 1.01
Board
P2 = PLC2.00
Board
Refer to
chapter 8 for
other
Configurations
Fieldbus
Communication
Boards:
Blank = Standard
DN = DeviceNet
PD = Profibus
DP
DD
=
DeviceNet
Profile
EN = EtherNet/IP
V1 = Profibus
DP-V1
Special
Hardware:
Blank =
Standard
HN = Without
DC Link
inductor
(only valid for
500-690V
and
660-690 V
models)
HD = DC Link
supply (refer
to chapter 8)
HC, HV = DC
Link inductor
(
Refer to
chapter 8)
(
Refer to
note)
220-230 V:
0006 = 6
A
0007 = 7 A
0010 = 10
A
0013 = 13
A
0016 = 16 A
0024 = 24 A
0028 = 28 A
0045 = 45 A
0054 = 54 A
0070 = 70 A
0086 = 86 A
0105 = 105 A
0130 = 130 A
380-480 V:
0003 = 3.6 A
0004 = 4 A
0005 = 5.5 A
0009 = 9 A
0013 = 13 A
0016 = 16 A
0024 = 24 A
0030 = 30 A
0038 = 38 A
0045 = 45 A
0060 = 60 A
0070 = 70 A
0086 = 86 A
0105 = 105 A
0142 = 142 A
0180 = 180 A
0211 = 211 A
0240 = 240 A
0312 = 312 A
0361 = 361 A
0450 = 450 A
0515 = 515 A
0600 = 600 A
Three-phase
power
supply.
Power
supply
voltage:
3848 =
380-480 V
2223 =
220-230 V
5060 =
500-600 V
5069 =
500-690 V
6669 =
660-690 V
500-600 V:
0002 = 2.9 A
0004 = 4.2 A
0007 = 7 A
0010 = 10 A
0012 = 12 A
0014 = 14 A
0022 = 22 A
0027 = 27 A
0032 = 32 A
0044 = 44 A
0053 = 53 A
0063 = 63 A
0079 = 79 A
500-690 V:
0107 = 107 A
0147 = 147 A
0211 = 211 A
0247 = 247 A
0315 = 315 A
0343 = 343 A
0418 = 418 A
0472 = 472 A
660-690 V:
0100 = 100 A
0127 = 127 A
0179 = 179 A
0225 = 225 A
0259 = 259 A
0305 = 305 A
0340 = 340 A
0428 = 428 A
Note:
- For rated output current specification of variable torque (VT), refer to chapter 9.
- The rated output current indicated for the models 500-690 V is only valid for 500 V to 600 V supply.
- For rated output current specification (CT and VT) of the models with supply voltage higher than 600 V, refer to chapter 9.
Note:
The option field (S or O) defines if the CFW-09 is a standard version or if it is equipped with any optional devices. If the standard version is required, the code ends here. The model
code number always has the letter Z at the end. For example:
CFW090045T2223ESZ = Standard 45 A CFW-09 inverter - three phase input at 220-230 V, with the Manual in English.
If the CFW-09 is equipped with any optional devices, you must fill out the fields in accordance to the optional devices desired in the correct sequence up to the last optional device
desired, then the model code number is completed with the letter Z.
Thus, for instance, if a product of the example above is required with an EBA expansion board, indicate:
CFW090045T2223EOA1Z = 45 A CFW-09 inverter – three-phase input at 220-230 V, with the manual in English and with the optional EBA.01 board.
Output rated current -
constant torque CT:
WEG
Series 09
Frequency
Inverter
Special
Software:
Blank =
Standard
S1 to Sn =
Special
Software
Version
SF = Metasys
N2 Protocol
SQ = Special
version for
DeviceNet
Drive Profile
Kit (indicate
option DD for
the Fieldbus
Communication
Board)
End of Code
(
refer to
note)
