CHAPTER 3 - INSTALLATIONANDCONNECTION
Figure 3.4 a) to c)
- Mounting procedure for the CFW-09 with the heatsink through the mounting surface
a) Sizes 1 and 2
Step3
Step 1
Step 2
Air
Flow
4mm(1/6in)max.
Step 2
Step 3
Step 1
Air
Flow
4mm(1/6in)max.
Sizes1and2
Sizes 3 to 8
b) Sizes 3 to 8E
c) Cutout Dimensions (Refer to table 3.4)
Kit-KMF
TopSupport
Kit-KMF
BottonSupport
