WinGD RT-flex50DF - Page 117

Maintenance
1224−1/A1
Winterthur Gas & Diesel Ltd.
5/ 6
ENGINE SIDEDRIVING END
CLOCKWISE
ROTATING ENGINE
VIEW FROM DRIVING END
PADS ON ENGINE SIDE
VIEW FROM DRIVING END
PADS AT DRIVING END
SUPPORT SURFACE
AHEAD
ASTERN
AHEADASTERN
COUNTERCLOCKWISE
ROTATING ENGINE
012.835/05
PROPELLER THRUST
AHEAD
PROPELLER THRUST
ASTERN
Fig. 4
Astern Pads Ahead Pads
CONFIGURATION OF THRUST BEARING PADS FOR CONTROLLABLE PITCH PROPELLER
5−Cyl and 6−Cyl ENGINE
2016
Thrust Bearing Pads − Removal and Installation
