WinGD RT-flex50DF - Page 118

Maintenance1224−1/A1
Winterthur Gas & Diesel Ltd.
6/ 6
ENGINE SIDEDRIVING END
SUPPORT SURFACE
VIEW FROM DRIVING END
PADS ON ENGINE SIDE
VIEW FROM DRIVING END
PADS AT DRIVING END
AHEADASTERN
CLOCKWISE
ROTATING ENGINE
COUNTERCLOCKWISE
ROTATING ENGINE
AHEADASTERN
012.834/05
PROPELLER THRUST
AHEAD
PROPELLER THRUST
ASTERN
Fig. 5
CONFIGURATION OF THRUST BEARING PADS FOR FIXED PITCH PROPELLER
7−Cyl and 8−Cyl ENGINE
Astern Pads Ahead Pads
2016
Thrust Bearing Pads − Removal and Installation
