PROSINE 2.0 INVERTER•CHARGER USER’S MANUAL
80
445-0089-01-01
Display Panel Faults
A message is displayed for any fault that is detected in the display panel. If a
Panel Fault message appears, you can clear it from the screen by pressing any
button on the panel. Since this type of fault does not trigger a shutdown,
operation of the system after the error occurs depends on the type of fault and
the setup of the system.
You can view the last ten Panel Fault messages by placing the unit in
Configure mode and then selecting View Last 10 Panel Faults from the
Diagnostics menu. The most recent fault is displayed first.
The majority of Panel Fault messages appear as
Internal Error nnnn
where nnnn is the number of the error.
If one of these errors causes the
inverter•charge
r to shut down, attempt to
restart the unit. If the error occurs again, call Xantrex.
Other faults are listed in Table 10.
Table 10 Panel Faults
Panel Faults Error Details
Panel Fault:
COMM1 Timeout
External communications
timeout Comm. Port 1
No transmission has been received for 2
seconds. Check the communications cable
between the display panel and the
inverter•charger as well as the
connectors.
Panel Fault:
COMM2 Timeout
External communications
timeout Comm. Port 2
No transmission has been received for 2
seconds. Check the communications cable
between the display panel and the
inverter•charger as well as the
connectors.
Panel Fault:
Data Not Sent
Menu data failed to be sent. After 5 retries, the data being altered on a
menu could not be updated to the destination
device.
Panel Fault:
Panel Unusable
The panel’s internal memory
has been corrupted.
The panel will not work.
The inverter•charger itself is not affected and
will continue to operate if you have selected
Run Without Panel.
To Next Page
