Xantrex PROsine 2.0

APPENDIX A SPECIFICATIONS
445-0089-01-01
99
Invert Power Derating vs Ambient Temperature
If the unit is in elevated ambient temperature above 40
°
C, you are required to
reduce power draw according to the following chart to maintain regulatory
compliance and to avoid over-temperature shutdown.
PROsine Charger Output Current vs AC Input Voltage
Inverter Output Power vs. Ambient
Temperature
0
500
1000
1500
2000
2500
-40-200 20406080
Ambient Temperature (°C)
Rated Continuous Outpu
Power (W)
Unit will run in
this area







Unit will run
in this area.
Unit may shut down in this area
Max Charge Current vs. Input AC Voltage
0
20
40
60
80
100
120
Input Vac (V rms)
Max Output Idc (A
)
Low Vac
Shutdow n
Level
Low Vac
Shutdow n + 2V
Low Vac
Shutdow n + 6V
135Vac
