PROSINE 2.0 INVERTER•CHARGER USER’S MANUAL
xviii 445-0089-01-01
MATERIALS LIST
Your PROsine
®
2.0 Inverter•Charger package includes the items listed below.
See Figure 1.
1 PROsine 2.0 Inverter•Charger
1 Display panel
1 Communications cable (70ft; 21m)
1 Battery temperature sensor with a 25ft (8m) cable
2 DC terminal covers
1 User’s Manual
1 Quick Installation Guide (includes inverter•charger mounting template)
1 Mounting template for display panel
1 Quick Reference Guide
1 ABYC Warning label. (See the Note on page xix.)
If any of these materials are missing or are unsatisfactory in any manner,
please contact Customer Service:
Phone: 1-800-670-0707 (Toll free) 1 360 925 5097 (Direct)
Fax: 1-360-925-5143
Email: customerservice@xantrex.com
NOTE
DC Wiring Enclosure
For residential installations, some installation codes may require a wiring
enclosure for DC connections and cables. (Installation procedures are
shipped with the DC Wiring Enclosure.)
Crimp-On Ring Terminals (for DC Wiring Enclosure)
If you are using the DC Wiring Enclosure, you should use crimp-on ring
terminals on the PROsine end of your DC cables. Most box connectors
(set screw types) are too large to fit in the enclosure without the risk of the
connector shorting to the wall of the DC Wiring Enclosure. Do not use
any connector that does not provide at least 2mm clearance to the inside
wall with the wire in place and the set screw tightened.
Series Sync Cable
If you are connecting two PROsine inverter•chargers in series, you will
need a Series Sync cable.
Contact Xantrex or your distributor about the Wiring Enclosure and the Series
Sync cable. Purchase the crimp-on ring terminals from a local supplier.
