Page #84 background image
PROSINE 2.0 INVERTER•CHARGER USERS MANUAL
58
445-0089-01-01
Diagnostics Menu
Menu Choices or Information Displayed
The screens on the Diagnostics menu are Read-Only. They let you monitor
and troubleshoot the status of your PROsine system. For example, if the unit is
continually recording Warnings about low battery voltage, you can view the
messages and take appropriate corrective action.
The following items appear on this menu:
PS System Mode
This screen indicates the present operating mode of the inverter•charger:
invert, bulk charge, absorption charge, etc.
View Last 20 PROsine Faults
The inverter•charger records the last twenty PROsine Warnings and
Errors. You can examine these for diagnostic and troubleshooting
purposes. (See Section 6: “Troubleshooting” starting on page 71.)
Warnings end with these characters: -W (e.g,. Batt too hot -W). Error
message are displayed in the same way without the -W at the end.
Menu Items Access
PS System Mode
Read-Only
View Last 20 PROsine Faults
PROsine Fault #0
•—
PROsine Fault #19
Read-Only
View Last 10 Panel Faults
Panel Fault #0
•—
Panel Fault #9
Read-Only
AC Bad Cause
Read-Only
View Software Versions:
LVP Software Revision
HVP Software Revision
Display Software Revision
Display EEPROM Revision
Read-Only
View System Temperatures:
Panel ambient temp
Unit Temp #1
Unit Temp #2
Read-Only
