Page #54 background image
PROSINE 2.0 INVERTER•CHARGER USERS MANUAL
28
445-0089-01-01
identified as the one that enables the automatic bonding system, and the other
hole defeats it so that the neutral is not bonded by the PROsine in any mode.
The PROsine is shipped with the screw in the position that enables the
automatic bonding system.
To disable the system, move the screw to the other hole.
Do not remove the screw from the product: make sure it is always
installed in one position or the other, as appropriate for the configuration
of the rest of the system.
Table 4 AC Output Neutral-to-Ground Bonding Screw Settings
Bonding
Screw Setting
Status of Bonding
Internal to the PROsine
Neutral Bonding Required
External to the PROsine
AC shorepower
not present (unit
Inverting or in
Standby)
AC shorepower
present (unit
Charging or in
Standby)
In the AC input
shorepower
source
In the AC load
panel
Automatic
bonding
Output neutral
bonded
Output neutral un-
bonded
Yes No
Un-bonded in
all modes
Output neutral un-
bonded
Output neutral un-
bonded
No Yes
