SECTION 4 CONFIGURATION
445-0089-01-01
59
■ View Last 10 Panel Faults
The display panel records the last ten faults that have occurred in the
display panel. You can view these for diagnostic and troubleshooting
purposes. (See “Display Panel Faults” starting on page 80.)
■ AC Bad Cause
If the input AC is not acceptable according to the configuration values
you set, this screen indicates why: causes included low frequency, low
voltage, etc. For a complete list of causes, see “AC Bad Causes‚” on
page 74.
■ View Software Versions
This information can help Xantrex Customer Service Representatives
troubleshoot problems you might have with the inverter•charger.
LVP Software Revision
HVP Software Revision
Display Software Revision
Display EEPROM Revision
■ View System Temperatures
These readings show temperatures in the inverter•charger and the display
panel.
Next Steps
At this point, you have configured the inverter•charger and display panel, and
you are now ready test and use the unit.
• Go to “Part 1: System Startup Check‚” on page 62.
