PROSINE 2.0 INVERTER•CHARGER USERS MANUAL
96
445-0089-01-01
Electrical Specifications: Invert Mode
Electrical Specifications: Charge Mode
DC Input
Operating voltage range 10.0V–16.0V
Safe non-operating voltage range 0–18Vdc
Nominal current at full load 200A
AC Output
Output voltage 117Vac
Continuous power 2.0kW, 2.0kVA to 40°C max. ambient
Surge power 4.5kW for 5s
Max short-circuit current 55Arms, 55Apk
Frequency 60.0Hz ±0.05%
Wave shape Sine
THD (over load range of 0–2.0kW
resistive)
2%
Power derating above 40°C ambient
temp
See
“Invert Power Derating vs Ambient
Temperature‚” on page 99
.
Peak efficiency
87%
Full load efficiency
83%
Other
Load power factor range 0–1, inductive, capacitive, or nonlinear, to 2kVA
No load input power (producing output
voltage)
25W
Load sense power
4W (1s interval)
2W (3s interval)
Standby mode power draw
(no output, display off)
≤0.5
W
Off mode current draw
2mA
AC Input
Operating voltage range 90–135Vac
Nominal current 15Aac at 100A charge, 120Vac in
Voltage wave shape Sine. The unit will not operate on, or pass
through, a modified sine-wave waveform.
Power factor (100A charge, 120Vac in)
0.98 on sine input
Nominal frequency 60Hz
DC Output
Nominal voltage 12.0Vdc
Min battery voltage for charging 0.0Vdc
Max output voltage 17.5Vdc
Nominal output current 100A @
15.0Vdc
Equalize mode max current
10A @
17.5Vdc
