SECTION 5 OPERATION
445-0089-01-01
69
PART 5: DISPLAY MODE SCREENS
When the DISPLAY switch is ON, you can view the screens shown below.
(The values shown here are examples only.) Display Mode screens are
updated continuously to show current PROsine 2.0 operating data. You can
scroll through them by pressing the Up
V
and
Down
W
MENU buttons.
Screen 1
Screen 2
Screen 3
Screen 4
NOTE
In the screens below current polarity is indicated as follows:
+
indicates current going into the battery (i.e. + indicates charging).
–
indicates current coming out of the battery (i.e. – indicates that the battery is
supplying loads or the
inverter•charger is
inverting).
OR
Shows the PROsine 2.0’s voltage and current readings from the battery as well
as the battery temperature. If the battery temperature sensor is not installed, the
screen on the right is displayed.
PROsine: Battery
12.0V +10A 22
°
C
PROsine: Battery
12.0V +10A
Shows the voltage, current, and frequency of the shorepower (i.e. input AC).
PROsine: AC In
118.0V 5A 58Hz
Shows the voltage, current, and frequency of the output AC.
PROsine: AC Out
120.0V 10A 60Hz
OR
Combines the battery display (Screen 1) with the AC output display (Screen 3).
The left-hand screen appears if the battery temperature sensor is installed.
Output AC is shown on the bottom. The PROsine’s voltage and current readings
from the battery as well as the battery temperature appear on top.
The bottom of the right-hand screen shows the output AC. The top shows
battery voltage and current as read by the PROsine. (This is the screen that
appears if the battery temperature sensor is not installed.)
12.0V –120A 22
°
C
120V 10A 60Hz
120V 10A 60Hz
12.0V –120A
To Next Page
