PROSINE 2.0 INVERTER•CHARGER USER’S MANUAL
34
445-0089-01-01
Step 8: Mounting the Display Panel
The communications cable supplied with the display panel is 70 feet long (21
meters). If you want to replace the cable with one that is longer or shorter, use
a high quality, 6-wire telephone extension cable. You can install the panel up
to 100 feet (30 meters) away from the inverter•charger.
Flush mounting the panel on a wall, bulkhead, or panel requires an opening
that is approximately 4 inches x 4 inches (10cm x 10cm). About 1 1/4 inches
(3cm) of free space is required within the wall to accommodate the depth of
the panel. Be sure there is no wiring or other obstructions within the wall
before you make an opening.
➢
➢➢
➢
To mount the display panel
1. Choose a location that is dry, out of direct sunlight, free from corrosive or
explosive fumes, and otherwise appropriate for mounting an electronic
device.
2. Tape the mounting template (in the PROsine 2.0 Inverter•Charger
package) to the mounting surface and mark the locations of the mounting
holes and the area to be cut away.
3. Pilot-drill the mounting holes and cut out the hole in which the panel will
be inserted.
4. Route the communications cable(s) inside the wall and through the
opening.
5. Insert one of the cable’s connectors in either jack on the bottom of the
panel.
6. Place the panel in the opening and secure it with appropriate fasteners.
7. Route the communications cable to the inverter•charger and insert the
connector in the jack labelled DISPLAY.
