SECTION 4 CONFIGURATION
445-0089-01-01
47
Configure PROsine—Basic Menu
Menu Choices or Information Displayed
■ AC Breaker Size
Set the AC breaker size to match the shorepower circuit breaker size to
reduce circuit breaker “nuisance” tripping. Values range from 0–30 amps.
■ Load Sensing
Select Enabled if you want the unit to only turn on when a load is present.
In Load Sense mode, the unit will periodically search for the presence of
an AC load while it is inverting. The unit will “sleep” if the load it detects
is less than the Load Sensing setting or if there is no load.
Select Disabled if you want the inverter on full-time rather than only
when a load is present.
For further information about load sensing, see “Load Sensing Mode” on
page 64.
■ Equalize
Select Enabled or Disabled. You can only select Enabled when the unit is
charging and battery type is set to Flooded.
An equalization charge must only be performed on flooded (non-sealed or
“wet”) batteries and only as often as recommended by the battery
manufacturer. For details about Equalization mode, see Appendix C:
“Batteries” starting on page 105.
Menu Items Access
AC Breaker Size
User
Load Sensing
User
Equalize
User
WARNING
If you select Enabled, you must monitor the electrolyte specific
gravity and level during the equalization phase to prevent over-
heating and battery damage.
CAUTION
During the equalization phase, the DC system voltage may exceed
17VDC, and therefore you should disconnect any sensitive DC
loads.
To Next Page
