Xantrex PROsine 2.0 User Manual

SECTION 2 PRODUCT ORIENTATION
445-0089-01-01
9
AC Panel Options
The PROsine 2.0 has two AC panel options, each of which includes one 30A
hardwire output circuit:
• Blank access panel: one hardwire output circuit. See Figure 2.
• Panel equipped with 15A GFCI receptacle and one hardwire output
circuit. See Figure 3.
Figure 3 Panel Equipped With GFCI and Circuit Protector
cd
Feature Description
c
GFCI Duplex Receptacle
d
15A circuit protector for GFCI
