SECTION 2 PRODUCT ORIENTATION
445-0089-01-01
13
CHARGER Switch
This switch is active in all Display modes: ON, OFF, CONFIGURE.
CHARGER LEDs
The LEDs are continuously updated whenever the Display Mode switch is set
to ON or CONFIGURE.
.
Switch Position Description
ENABLE The charger is enabled and will charge the battery according to the
way the unit is configured if shorepower is “good.”
DISABLE The charger is off and will consume minimal power.
LED Description
STANDBY
and
STANDBY
LED Status
CHARGING
LED Status
OFF OFF The charger is not running because it is not
enabled, the charge cycle has been
completed, or a system error has occurred.
OFF ON The charger is running.
CHARGING
ON OFF The charger is enabled but is not running
because shorepower is not “good.”
EQUALIZE
OFF Equalize mode has not been selected.
ON The charger is in Equalize mode and the
batteries are charging.
CAUTION:
Battery voltage may go up to
17V.
FLASHING Equalize mode has been selected; the
charger is presently executing the basic
charge cycle in preparation for
Equalization mode. (The CHARGING
LED is also on in this stage.)
READY
OFF The charger is not running, or the Charge
cycle is not finished.
ON The Charge cycle is complete. The battery
is fully charged.
