Xantrex PROsine 2.0 User Manual

445-0089-01-01 45
S
ECTION 4 CONFIGURATION
Table 5 Menu Structure—Overview
Configure PROsine—Basic Configure PROsine—Advanced Configure Display Panel Configure Battery Diagnostics AC Breaker Size Load Sensing Equalize
Load Sensing Load Sense Power Load Sense Interval Low AC Transfer (V) Low AC Transfer (Hz) High AC Transfer (V) High AC Transfer (Hz) AC Series Mode Inverter Low V Shutdown Run Without Panel Inverter Enabled on Reset
Without Panel
Charger Enabled on Reset
Without Panel
Auto Restart After Error Reset to Defaults
Audible Alarm LCD Backlight Mode LCD Backlight Brightness LCD Backlight Timeout Temperature (C/F)
Battery Size Default Battery Temp Battery Type View/Change Battery Details: • Battery Temp. Coefficient • Bulk Charge Mode Settings
• Max Voltage • Max Current (%C) •Exit Voltage •Exit Timeout
• Absorption Mode Settings:
• Max Voltage • Max Current (%C) • Max Time • Exit Current (%C) •Exit Timeout
• Overcharge Mode Settings:
• Max Voltage • Max Current (%C) • Max Time
• Float Mode Settings:
• Max Voltage • Max Current (%C) • Max Time •Exit Voltage •Exit Timeout
• Equalize Mode Settings:
• Max Voltage • Max Current (%C) • Max Time • Exit Change •Exit Timeout
• Constant Mode Settings:
• Voltage Setpoint • Current Setpoint
Charger Mode Charger Type
PS System Mode View Last 20 PROsine Faults View Last 10 Panel Faults AC Bad Cause View Software Versions: • LVP Software Revision • HVP Software Revision • Display Software Revision • Display EEPROM Revision View System Temperatures: • Temperature at Panel • PROsine Unit Temp. 1 • PROsine Unit Temp. 2
NOTE:
When there is a system error,
the following top level configuration menu appears:
Clear Error?
