APPENDIX A SPECIFICATIONS
445-0089-01-01 97
Environmental Specifications
System
Regulatory Approvals
Charger current derating Automatically reduce charger current as internal
temperature exceeds 80
°C, input Vac
approaches low transfer, and ac input current
approaches 80% of breaker setting.
Efficiency at nominal output t84%
Other
Battery type settings Gel, Flooded, AGM, Pb-Ca
Battery size settings 50–2000 Ahr
Charge algorithms Custom 3-stage with factory default set points.
Custom 2-stage as above.
Manually engaged, equalize, with factory
defaults.
CV/CC. User programmable setpoints.
Independent battery banks 1
Ambient Temperature:
Operating Temperature Range
Storage Temperature Range
–20–60ºC, with output derated above 40
°C
–40–70ºC
Humidity: Operation/Storage 5–95% RH, non-condensing
Transfer relay rating 30A, 1.5hp
Transfer time 16ms
Transfer on bad voltage 85–110V for low AC and 120–135 for high AC,
user-adjustable.
Transfer on bad frequency 40–70Hz user-adjustable for high and low
frequency limits.
Inverter synchronized to line before
transfer
Yes
Remote ON/OFF An isolated input to the unit where, with 5–18V
applied the unit operates normally, with <1V the
unit is off.
Cooling Fan, activated by any of the following:
High internal temperature
High AC input current
High AC output current
CSA/NRTL approved to CSA 107.1, UL458 (including Marine Supplement), and UL1741
Complies with ABYC recommended practices E-8, E-9, A-20, and A-25 for marine use
Compliance to KKK-A-1822D for use in “Star-of-Life” ambulances available on request
