PROSINE 2.0 INVERTER•CHARGER USERS MANUAL
90
445-0089-01-01
Installing the Display Panels
Mount and connect the display panel for each inverter•charger. (For
details, see “Step 8: Mounting the Display Panel‚” on page 34.)
Installing the Battery Temperature Sensors
For optimal charging, each inverter•charger must have its own battery
temperature sensor.
Single Bank: If your system has a single bank, install both sensors on the
battery (or batteries) which will be the hottest.
Two Separate Banks: If your system has two separate battery banks,
connect one sensor to either inverter•charger and then to the battery it is
charging; connect the second sensor to the second inverter•charger and
then to the battery it is charging.
For additional installation details, see page 35.
Installing the Series Sync Cable
To install the series sync cable
1. Connect the series sync cable from the SYNC jack on one
inverter•charger to the SYNC jack on the other unit.
2. Secure the cable to prevent strain on the connections.
NOTE
Each inverter•charger must have its own panel so you can properly
monitor and control the system.
WARNING: Explosion Hazard
If the charger has been operating, wait ten minutes for any explosive
battery gases to dissipate
.
