SECTION 4 CONFIGURATION
445-0089-01-01
43
Changing Settings
➢
➢➢
➢
To change system settings
1. Set the
DISPLAY
switch to
CONFIGURE
.
2. Press Up
V
MENU or Down
W
MENU
to display the menu you want.
3. Press
ENTER
once, and then press Up
V
MENU or Down
W
MENU
until
the menu item you want appears.
4. Press Up
V
DATA or Down
W
DATA
until the value you want appears.
5. Press Up
V
MENU or Down
W
MENU
until the setting you want
appears.
6. When the correct value is displayed, you can do one of three things:
• Press ENTER to save the new setting.
• Press ESCAPE to restore the old setting.
•Press Up
V
MENU or Down
W
MENU
to restore the old setting and
move to another item on the same menu.
Changing Settings: Example 1
The Audible Alarm is set to Disabled by default. If you want to change it to
All Faults, here are the steps you take:
1. Set the
DISPLAY
switch to
CONFIGURE
.
2. Press Down
W
MENU
until
Configure Display Panel
appears.
3. Press
ENTER
once. The
Audible Alarm
menu item appears with an
asterisk (*) beside
Disabled
.
4. Press down
W
DATA
until
All Faults
appears.
5. Press
ENTER
to save this setting. (An
*
appears to the left of
All Faults
.)
Changing Settings: Example 2
Let’s say you need to adjust the Breaker Size setting. Here’s how you do it:
1. Set the
DISPLAY
switch to
CONFIGURE
:
Configure PROsine—Basic
appears.
2. Press the
ENTER
button once.
AC Breaker Size
appears.
3. Press Down
W
DATA or Up
V
DATA
until the value you want appears.
4. Press
ENTER
to save this setting.
NOTE
All configuration settings are stored in the PROsine’s memory and will not be lost
even if all power is disconnected.
NOTE
Wherever you are in the menu structure, you can return to the highest level by
repeatedly pressing ESCAPE.
