PROSINE 2.0 INVERTER•CHARGER USER’S MANUAL
42
445-0089-01-01
PART 1: GENERAL CONFIGURATION INFORMATION
All changes to the operation of the PROsine 2.0 Inverter•Charger are made via
the display panel. The unit must be in Configure mode or Installer-Only mode
before you can change system settings. It is essential that you understand the
implications of changing User and Installer settings. Be sure to study Section
3 before you configure your system. Procedures for changing modes and
values are given below.
Entering Configure Mode
➢
➢➢
➢
To enter Configure mode
•Set the
DISPLAY
switch to
CONFIGURE
.
This gives you access to all user-configurable items.
Entering Installer-Only Mode
If you try to change settings on a screen that contains installer-only data and
the panel is not in Installer mode, this message appears for one second:
To Change; Enter Installer Mode
➢
➢➢
➢
To enter Installer-Only mode
• While the unit is in Configure mode, hold down the
ESCAPE
and
DATA
Down
W
buttons for 3–4 seconds.
A message cautions you that the panel is now in Installer mode and
explains how to exit Installer mode.
The next time you press a key, a message appears to remind you that the
panel is still in Installer mode.
Exit Installer-Only mode before you put the inverter•charger into service.
WARNING
The following information is for qualified installation/service personnel
only. Incorrect configuration can lead to battery damage and risk of fire.
If a parameter is “Installer-Only,” it is meant to be configured by a
professional installer who is not only familiar with the system settings
on the inverter but also the ramifications of changing those settings.
Setting these parameters incorrectly could damage connected
equipment (e.g. batteries) or could severely affect the performance of
your system. You will not be able to change parameters that are
Installer-Only unless you place the display panel in Installer-Only
mode.
